Order Guide
Catalogue No | Height | Width | Depth | Product Information |
---|---|---|---|---|
LQF140404 | 1399 | 399 | 399 | |
LQF140504 | 1399 | 499 | 399 | |
LQF140604 | 1399 | 599 | 399 | |
LQF140804 | 1399 | 799 | 399 | |
LQF141004 | 1399 | 999 | 399 | |
LQF141204 | 1399 | 1199 | 399 | |
LQF140505 | 1399 | 399 | 499 | |
LQF140605 | 1399 | 599 | 499 | |
LQF140805 | 1399 | 799 | 499 | |
LQF141005 | 1399 | 999 | 499 | |
LQF141205 | 1399 | 1199 | 499 | |
LQF140606 | 1399 | 599 | 599 | |
LQF140806 | 1399 | 799 | 599 | |
LQF141006 | 1399 | 999 | 599 | |
LQF141206 | 1399 | 1199 | 599 | |
LQF140808 | 1399 | 799 | 799 | |
LQF141008 | 1399 | 999 | 799 | |
LQF141208 | 1399 | 1199 | 799 | |
LQF160404 | 1599 | 399 | 399 | |
LQF160504 | 1599 | 499 | 399 | |
LQF160604 | 1599 | 599 | 399 | |
LQF160804 | 1599 | 799 | 399 | |
LQF161004 | 1599 | 999 | 399 | |
LQF161204 | 1599 | 1199 | 399 | |
LQF160505 | 1599 | 499 | 499 | |
LQF160605 | 1599 | 599 | 499 | |
LQF160805 | 1599 | 799 | 499 | |
LQF161005 | 1599 | 999 | 499 | |
LQF161205 | 1599 | 1199 | 499 | |
LQF160606 | 1599 | 599 | 599 | |
LQF160806 | 1599 | 799 | 599 | |
LQF161006 | 1599 | 999 | 599 | |
LQF161206 | 1599 | 1199 | 599 | |
LQF160808 | 1599 | 799 | 799 | |
LQF161008 | 1599 | 999 | 799 | |
LQF161208 | 1599 | 1199 | 799 | |
LQF180404 | 1799 | 399 | 399 | |
LQF180504 | 1799 | 499 | 399 | |
LQF180604 | 1799 | 599 | 399 | |
LQF180804 | 1799 | 799 | 399 | |
LQF181004 | 1799 | 999 | 399 | |
LQF181204 | 1799 | 1199 | 399 | |
LQF180505 | 1799 | 499 | 499 | |
LQF180605 | 1799 | 599 | 499 | |
LQF180805 | 1799 | 799 | 499 | |
LQF181005 | 1799 | 999 | 499 | |
LQF181205 | 1799 | 1199 | 499 | |
LQF180606 | 1799 | 599 | 599 | |
LQF180806 | 1799 | 799 | 599 | |
LQF181006 | 1799 | 999 | 599 | |
LQF181206 | 1799 | 1199 | 599 | |
LQF180808 | 1799 | 799 | 799 | |
LQF181008 | 1799 | 999 | 799 | |
LQF181208 | 1799 | 1199 | 799 | |
LQF200404 | 1999 | 399 | 399 | |
LQF200504 | 1999 | 499 | 399 | |
LQF200604 | 1999 | 599 | 399 | |
LQF200804 | 1999 | 799 | 399 | |
LQF201004 | 1999 | 999 | 399 | |
LQF201204 | 1999 | 1199 | 399 | |
LQF200505 | 1999 | 499 | 499 | |
LQF200605 | 1999 | 599 | 499 | |
LQF200805 | 1999 | 799 | 499 | |
LQF201005 | 1999 | 999 | 499 | |
LQF201205 | 1999 | 1199 | 499 | |
LQF200606 | 1999 | 599 | 599 | |
LQF200806 | 1999 | 799 | 599 | |
LQF201006 | 1999 | 999 | 599 | |
LQF201206 | 1999 | 1199 | 599 | |
LQF200808 | 1999 | 799 | 799 | |
LQF201008 | 1999 | 999 | 799 | |
LQF201208 | 1999 | 1199 | 799 | |
LQF220404 | 2199 | 399 | 399 | |
LQF220504 | 2199 | 499 | 399 | |
LQF220604 | 2199 | 599 | 399 | |
LQF220804 | 2199 | 799 | 399 | |
LQF221004 | 2199 | 999 | 399 | |
LQF221204 | 2199 | 1199 | 399 | |
LQF220505 | 2199 | 499 | 499 | |
LQF220605 | 2199 | 599 | 499 | |
LQF220805 | 2199 | 799 | 499 | |
LQF221005 | 2199 | 999 | 499 | |
LQF221205 | 2199 | 1199 | 499 | |
LQF220606 | 2199 | 599 | 599 | |
LQF220806 | 2199 | 799 | 599 | |
LQF221006 | 2199 | 999 | 599 | |
LQF221206 | 2199 | 1199 | 599 | |
LQF220808 | 2199 | 799 | 799 | |
LQF221008 | 2199 | 999 | 799 | |
LQF221208 | 2199 | 1199 | 799 |
Catalogue No | Height | Width | Depth | Product Information | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Catalogue No | External Single Door | Door Rail Fixing Points | Internal Stiffener Rail | Window Opening | |||||||
Solid Door | Window Door | Vented Door | (H1) Height | (W1) Width | (H2) Height | (W2) Width | (H3) Height | (W3) Width | (H4) Height | (W4) Width | |
LQD1404 | - | - | 1358 | 372 | 1269 | 269 | 1250 | 250 | - | - | Product Information |
LQD1405 | LQD1405/W | LQD1405/V | 1358 | 472 | 1269 | 369 | 1250 | 350 | 1220 | 320 | |
LQD1406 | LQD1406/W | LQD1406/V | 1358 | 572 | 1269 | 469 | 1250 | 450 | 1220 | 420 | |
LQD1408 | LQD1408/W | LQD1408/V | 1358 | 772 | 1269 | 669 | 1250 | 650 | 1220 | 620 | |
LQD1604 | - | - | 1558 | 372 | 1469 | 269 | 1450 | 250 | - | - | |
LQD1605 | LQD1605/W | LQD1605/V | 1558 | 472 | 1469 | 369 | 1450 | 350 | 1420 | 320 | |
LQD1606 | LQD1606/W | LQD1606/V | 1558 | 572 | 1469 | 469 | 1450 | 450 | 1420 | 420 | |
LQD1608 | LQD1608/W | LQD1608/V | 1558 | 772 | 1469 | 669 | 1450 | 650 | 1420 | 620 | |
LQD1804 | - | – | 1758 | 372 | 1669 | 269 | 1650 | 250 | – | – | |
LQD1805 | LQD1805/W | LQD1805/V | 1758 | 472 | 1669 | 369 | 1650 | 350 | 1620 | 320 | |
LQD1806 | LQD1806/W | LQD1806/V | 1758 | 572 | 1669 | 469 | 1650 | 450 | 1620 | 420 | |
LQD1808 | LQD1808/W | LQD1808/V | 1758 | 772 | 1669 | 669 | 1650 | 650 | 1620 | 620 | |
LQD2004 | – | – | 1958 | 372 | 1869 | 269 | 1850 | 250 | – | – | |
LQD2005 | LQD2005/W | LQD2005/V | 1958 | 472 | 1869 | 369 | 1850 | 350 | 1820 | 320 | |
LQD2006 | LQD2006/W | LQD2006/V | 1958 | 572 | 1869 | 469 | 1850 | 450 | 1820 | 420 | |
LQD2008 | LQD2008/W | LQD2008/V | 1958 | 772 | 1869 | 669 | 1850 | 650 | 1820 | 620 | |
LQD2204 | – | – | 2158 | 372 | 2069 | 269 | 2050 | 250 | – | – | |
LQD2205 | LQD2205/W | LQD2205/V | 2158 | 472 | 2069 | 369 | 2050 | 350 | 2020 | 320 | |
LQD2206 | LQD2206/W | LQD2206/V | 2158 | 572 | 2069 | 469 | 2050 | 450 | 2020 | 420 | |
LQD2208 | LQD2208/W | LQD2208/V | 2158 | 772 | 2069 | 669 | 2050 | 650 | 2020 | 620 |
Catalogue No | Height | Width | Depth | Product Information | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Catalogue No | External Door | Door Rail Fixing Points | Internal Stiffener Rail | Window Opening | |||||||
Solid Door | Window Door | Vented Door | (H1) Height | (W1) Width | (H2) Height | (W2) Width | (H3) Height | (W3) Width | (H4) Height | (W4) Width | |
LQDD1406 | LQDD1406/W | LQDD1406/V | 1358 | 568 | 1269 | 169 | 1250 | 150 | 1220 | 120 | Product Information |
LQDD1408 | LQDD1408/W | LQDD1408/V | 1358 | 768 | 1269 | 269 | 1250 | 250 | 1220 | 220 | |
LQDD1410 | LQDD1410/W | LQDD1410/V | 1358 | 968 | 1269 | 369 | 1250 | 350 | 1220 | 320 | |
LQDD1412 | LQDD1412/W | LQDD1412/V | 1358 | 1168 | 1269 | 469 | 1250 | 450 | 1220 | 420 | |
LQDD1606 | LQDD1606/W | LQDD1606/V | 1558 | 568 | 1469 | 169 | 1450 | 150 | 1420 | 120 | |
LQDD1608 | LQDD1608/W | LQDD1608/V | 1558 | 768 | 1469 | 269 | 1450 | 250 | 1420 | 220 | |
LQDD1610 | LQDD1610/W | LQDD1610/V | 1558 | 968 | 1469 | 369 | 1450 | 350 | 1420 | 320 | |
LQDD1612 | LQDD1612/W | LQDD1612/V | 1558 | 1168 | 1469 | 469 | 1450 | 450 | 1420 | 420 | |
LQDD1806 | LQDD1806/W | LQDD1806/V | 1758 | 568 | 1669 | 169 | 1650 | 150 | 1620 | 120 | |
LQDD1808 | LQDD1808/W | LQDD1808/V | 1758 | 768 | 1669 | 269 | 1650 | 250 | 1620 | 220 | |
LQDD1810 | LQDD1810/W | LQDD1810/V | 1758 | 968 | 1669 | 369 | 1650 | 350 | 1620 | 320 | |
LQDD1812 | LQDD1812/W | LQDD1812/V | 1758 | 1168 | 1669 | 469 | 1650 | 450 | 1620 | 420 | |
LQDD2006 | LQDD2006/W | LQDD2006/V | 1958 | 568 | 1869 | 169 | 1850 | 150 | 1820 | 120 | |
LQDD2008 | LQDD2008/W | LQDD2008/V | 1958 | 768 | 1869 | 269 | 1850 | 250 | 1820 | 220 | |
LQDD2010 | LQDD2010/W | LQDD2010/V | 1958 | 968 | 1869 | 369 | 1850 | 350 | 1820 | 320 | |
LQDD2012 | LQDD2012/W | LQDD2012/V | 1958 | 1168 | 1869 | 469 | 1850 | 450 | 1820 | 420 | |
LQDD2206 | LQDD2206/W | LQDD2206/V | 2158 | 568 | 2069 | 169 | 2050 | 150 | 2020 | 120 | |
LQDD2208 | LQDD2208/W | LQDD2208/V | 2158 | 768 | 2069 | 269 | 2050 | 250 | 2020 | 220 | |
LQDD2210 | LQDD2210/W | LQDD2210/V | 2158 | 968 | 2069 | 369 | 2050 | 350 | 2020 | 320 | |
LQDD2212 | LQDD2212/W | LQDD2212/V | 2158 | 1168 | 2069 | 469 | 2050 | 450 | 2020 | 420 |
Catalogue No | Height | Width | Depth | Product Information |
---|---|---|---|---|
Catalogue No. | ||||
Fixed Panel | Hinged Panel | Height | Width | |
LQCF1404 | LQCP1404 | 1358 | 370 | Product Information |
LQCF1405 | LQCP1405 | 1358 | 470 | |
LQCF1406 | LQCP1406 | 1358 | 570 | |
LQCF1408 | LQCP1408 | 1358 | 770 | |
LQCF1410 | LQCP1410 | 1358 | 970 | |
LQCF1412 | LQCP1412 | 1358 | 1170 | |
LQCF1604 | LQCP1604 | 1558 | 370 | |
LQCF1605 | LQCP1605 | 1558 | 470 | |
LQCF1606 | LQCP1606 | 1558 | 570 | |
LQCF1608 | LQCP1608 | 1558 | 770 | |
LQCF1610 | LQCP1610 | 1558 | 970 | |
LQCF1612 | LQCP1612 | 1558 | 1170 | |
LQCF1804 | LQCP1804 | 1758 | 370 | |
LQCF1805 | LQCP1805 | 1758 | 470 | |
LQCF1806 | LQCP1806 | 1758 | 570 | |
LQCF1808 | LQCP1808 | 1758 | 770 | |
LQCF1810 | LQCP1810 | 1758 | 970 | |
LQCF1812 | LQCP1812 | 1758 | 1170 | |
LQCF2004 | LQCP2004 | 1958 | 370 | |
LQCF2005 | LQCP2005 | 1958 | 470 | |
LQCF2006 | LQCP2006 | 1958 | 570 | |
LQCF2008 | LQCP2008 | 1958 | 770 | |
LQCF2010 | LQCP2010 | 1958 | 970 | |
LQCF2012 | LQCP2012 | 1958 | 1170 | |
LQCF2204 | LQCP2204 | 2158 | 370 | |
LQCF2205 | LQCP2205 | 2158 | 470 | |
LQCF2206 | LQCP2206 | 2158 | 570 | |
LQCF2208 | LQCP2208 | 2158 | 770 | |
LQCF2210 | LQCP2210 | 2158 | 970 | |
LQCF2212 | LQCP2212 | 2158 | 1170 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Catalogue No. | External Dimensions (mm) | Fixing Dimensions (mm) | |||
Flat Top | Vented Top | Width | Depth | Width | |
LQTF0404 | LQTV0404 | 399 | 399 | 292 | Product Information |
LQTF0405 | LQTV0405 | 399 | 499 | 292 | |
LQTF0406 | LQTV0406 | 399 | 599 | 292 | |
LQTF0408 | LQTV0408 | 399 | 799 | 292 | |
LQTF0410 | LQTV0410 | 399 | 999 | 292 | |
LQTF0412 | LQTV0412 | 399 | 1999 | 292 | |
LQTF0504 | LQTV0504 | 499 | 399 | 392 | |
LQTF0505 | LQTV0505 | 499 | 499 | 392 | |
LQTF0506 | LQTV0506 | 499 | 599 | 392 | |
LQTF0508 | LQTV0508 | 499 | 799 | 392 | |
LQTF0510 | LQTV0510 | 499 | 999 | 392 | |
LQTF0512 | LQTV0512 | 499 | 1999 | 392 | |
LQTF0604 | LQTV0604 | 599 | 399 | 492 | |
LQTF0605 | LQTV0605 | 599 | 499 | 492 | |
LQTF0606 | LQTV0606 | 599 | 599 | 492 | |
LQTF0608 | LQTV0608 | 599 | 799 | 492 | |
LQTF0610 | LQTV0610 | 599 | 999 | 492 | |
LQTF0612 | LQTV0612 | 599 | 1999 | 492 | |
LQTF0804 | LQTV0804 | 799 | 399 | 692 | |
LQTF0805 | LQTV0805 | 799 | 499 | 692 | |
LQTF0806 | LQTV0806 | 799 | 599 | 692 | |
LQTF0808 | LQTV0808 | 799 | 799 | 692 | |
LQTF0810 | LQTV0810 | 799 | 999 | 692 | |
LQTF0812 | LQTV0812 | 799 | 1999 | 692 | |
LQTF1004 | LQTV1004 | 999 | 399 | 892 | |
LQTF1005 | LQTV1005 | 999 | 499 | 892 | |
LQTF1006 | LQTV1006 | 999 | 599 | 892 | |
LQTF1008 | LQTV1008 | 999 | 799 | 892 | |
LQTF1204 | LQTV1204 | 1199 | 399 | 1092 | |
LQTF1205 | LQTV1205 | 1199 | 499 | 1092 | |
LQTF1206 | LQTV1206 | 1199 | 599 | 1092 | |
LQTF1208 | LQTV1208 | 1199 | 799 | 1092 |
Catalogue No | Height | Width | Depth | Product Information | |||
---|---|---|---|---|---|---|---|
Catalogue No. | External Dimensions (mm) | Opening Dimensions (mm) | Mounting Centres (mm) | ||||
Height | Width | Depth | Width | Depth | Width | ||
LQPB010404 | 100 | 399 | 399 | 251 | 251 | 269 | Product Information |
LQPB010504 | 100 | 499 | 399 | 351 | 251 | 369 | |
LQPB010604 | 100 | 599 | 399 | 451 | 251 | 469 | |
LQPB010804 | 100 | 799 | 399 | 651 | 251 | 669 | |
LQPB011004 | 100 | 999 | 399 | 851 | 251 | 869 | |
LQPB011204 | 100 | 1199 | 399 | 1051 | 251 | 1069 | |
LQPB010405 | 100 | 399 | 499 | 251 | 351 | 269 | |
LQPB010505 | 100 | 499 | 499 | 351 | 351 | 369 | |
LQPB010605 | 100 | 599 | 499 | 451 | 351 | 469 | |
LQPB010805 | 100 | 799 | 499 | 651 | 351 | 669 | |
LQPB011005 | 100 | 999 | 499 | 851 | 351 | 869 | |
LQPB011205 | 100 | 1199 | 499 | 1051 | 351 | 1069 | |
LQPB010406 | 100 | 399 | 599 | 251 | 451 | 269 | |
LQPB010506 | 100 | 499 | 599 | 351 | 451 | 369 | |
LQPB010606 | 100 | 599 | 599 | 451 | 451 | 469 | |
LQPB010806 | 100 | 799 | 599 | 651 | 451 | 669 | |
LQPB011006 | 100 | 999 | 599 | 851 | 451 | 869 | |
LQPB011206 | 100 | 1199 | 599 | 1051 | 451 | 1069 | |
LQPB010408 | 100 | 399 | 799 | 251 | 651 | 269 | |
LQPB010508 | 100 | 499 | 799 | 351 | 651 | 369 | |
LQPB010608 | 100 | 599 | 799 | 451 | 651 | 469 | |
LQPB010808 | 100 | 799 | 799 | 651 | 651 | 669 | |
LQPB011008 | 100 | 999 | 799 | 851 | 651 | 869 | |
LQPB011208 | 100 | 1199 | 799 | 1051 | 651 | 1069 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
External Dimensions (mm) | Fixing Dimensions (mm) | ||||
Catalogue No. | Height | Width | Width | Width | |
LQP0104 | 100 | 398 | 372 | 199 | Product Information |
LQP0105 | 100 | 498 | 472 | 299 | |
LQP0106 | 100 | 598 | 572 | 399 | |
LQP0108 | 100 | 798 | 772 | 599 | |
LQP0110 | 100 | 998 | 972 | 799 | |
LQP0112 | 100 | 1198 | 1172 | 999 | |
LQP0204 | 200 | 396 | 372 | 199 | |
LQP0205 | 200 | 496 | 472 | 299 | |
LQP0206 | 200 | 596 | 572 | 399 | |
LQP0208 | 200 | 796 | 772 | 599 | |
LQP0210 | 200 | 996 | 972 | 799 | |
LQP0212 | 200 | 1196 | 1172 | 999 | |
LQGK0404 | 243 | 243 | 270 | 270 | Product Information |
BRLED300 | • | • | • | Product Information | |
The baying kit available for iLINQ is designed to be fitted in a multitude of places, maximising space and flexibility. | |||||
Catalogue No | Description | ||||
LQBK | Baying kit (8 external / 10 internal) /gasket tape/plinth infill | Product Information | |||
LQMF1401 | Mounting pan infill 1400 high | ||||
LQMF1601 | Mounting pan infill 1600 high | ||||
LQMF1801 | Mounting pan infill 1800 high |
Catalogue No | Height | Width | Product Information |
---|---|---|---|
External Dimensions (mm) | |||
Catalogue No. | Height | Width | |
LQPC0104 | 111 | 277 | Product Information |
LQPC0105 | 111 | 377 | |
LQPC0106 | 111 | 477 | |
LQPC0108 | 111 | 677 | |
LQPC0110 | 111 | 877 | |
LQPC0112 | 111 | 1077 | |
LQPC0204 | 211 | 277 | |
LQPC0205 | 211 | 377 | |
LQPC0206 | 211 | 477 | |
LQPC0208 | 211 | 677 | |
LQPC0210 | 211 | 877 | |
LQPC0212 | 211 | 1077 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Catalogue No. | Opening Size (mm) | Plate Size (mm) | |||
Width | Depth | Width | Depth | ||
LQGK0404 | 243 | 243 | 270 | 270 | Product Information |
LQGK0504 | 343 | 243 | 370 | 270 | |
LQGK0604 | 443 | 243 | 470 | 270 | |
LQGK0804 | 643 | 243 | 670 | 270 | |
LQGK1004 | 843 | 243 | 870 | 270 | |
LQGK1204 | 1043 | 243 | 1070 | 270 | |
LQGK0505 | 343 | 343 | 370 | 370 | |
LQGK0605 | 443 | 343 | 470 | 370 | |
LQGK0805 | 643 | 343 | 670 | 370 | |
LQGK1005 | 843 | 343 | 870 | 370 | |
LQGK1205 | 1043 | 343 | 1070 | 370 | |
LQGK0606 | 443 | 443 | 470 | 470 | |
LQGK0806 | 643 | 443 | 670 | 470 | |
LQGK1006 | 843 | 443 | 870 | 470 | |
LQGK1206 | 1043 | 443 | 1070 | 470 | |
LQGK0808 | 643 | 643 | 670 | 670 | |
LQGK1008 | 843 | 643 | 870 | 670 | |
LQGK1208 | 1043 | 643 | 1070 | 670 | |
LQGK0606/GA | Full width | 3 | 449 | 449 | Product Information |
LQGK0806/GA | 3 | 649 | 449 | ||
LQGK1006/GA | Centre Mullion | 6 | 849 | 449 | |
LQGK1206/GA | 6 | 1049 | 449 | ||
LQGK0608/GA | Full width | 3 | 449 | 649 | |
LQGK0808/GA | 3 | 649 | 649 | ||
LQGK1008/GA | Centre Mullion | 6 | 849 | 649 | |
LQGK1208/GA | 6 | 1049 | 649 |
Catalogue No | Height | Width | Depth | Product Information | |||||
---|---|---|---|---|---|---|---|---|---|
Depth Series | Catalogue No. | Opening Size (mm) | Plate Size (mm) | ||||||
Gland Frame | Gland Plate – 1.6 mm steel | Gland Plate – 6 mm Aluminium | Gland Plate – 3 mm Brass | Width | Depth | Width | Depth | ||
400mm | LQGF0404 | LQGP0404 | LQGP0404/A6 | LQGP0404/B3 | 243 | 243 | 270 | 270 | Product Information |
LQGF0504 | LQGP0604 | LQGP0604/A6 | LQGP0604/B3 | 343 | 243 | 370 | 270 | ||
LQGF0604 | LQGP0604 | LQGP0604/A6 | LQGP0604/B3 | 443 | 243 | 470 | 270 | ||
LQGF0804 | LQGP0804 | LQGP0804/A6 | LQGP0804/B3 | 643 | 243 | 670 | 270 | ||
LQGF1004 | LQGP1004 | LQGP1004/A6 | LQGP1004/B3 | 843 | 243 | 870 | 270 | ||
LQGF1204 | LQGP1204 | LQGP1204/A6 | LQGP1204/B3 | 1043 | 243 | 1070 | 270 | ||
500mm | LQGF0505 | LQGP0505 | LQGP0505/A6 | LQGP0505/B3 | 343 | 343 | 370 | 370 | |
LQGF0605 | LQGP0605 | LQGP0605/A6 | LQGP0605/B3 | 443 | 343 | 470 | 370 | ||
LQGF0805 | LQGP0805 | LQGP0805/A6 | LQGP0805/B3 | 643 | 343 | 670 | 370 | ||
LQGF1005 | LQGP1005 | LQGP1005/A6 | LQGP1005/B3 | 843 | 343 | 870 | 370 | ||
LQGF1205 | LQGP1205 | LQGP1205/A6 | LQGP1205/B3 | 1043 | 343 | 1070 | 370 | ||
600mm | LQGF0606 | LQGP0606 | LQGP0606/A6 | LQGP0606/B3 | 443 | 443 | 470 | 470 | |
LQGF0806 | LQGP0806 | LQGP0806/A6 | LQGP0806/B3 | 643 | 443 | 670 | 470 | ||
LQGF1006 | LQGP1006 | LQGP1006/A6 | LQGP1006/B3 | 843 | 443 | 870 | 470 | ||
LQGF1206 | LQGP1206 | LQGP1206/A6 | LQGP1206/B3 | 1043 | 443 | 1070 | 470 | ||
800mm | LQGF0808 | LQGP0808 | LQGP0808/A6 | LQGP0808/B3 | 643 | 643 | 670 | 670 | |
LQGF1008 | LQGP1008 | LQGP1008/A6 | LQGP1008/B3 | 843 | 643 | 870 | 670 | ||
LQGF1208 | LQGP1208 | LQGP1208/A6 | LQGP1208/B3 | 1043 | 643 | 1070 | 670 |
Catalogue No | Height | Width | Depth | Product Information | |||
---|---|---|---|---|---|---|---|
Opening Size (mm) | Overall Plate Size (mm) | Individual Plate Size (mm) | |||||
Catalogue No. | Construction | Number of Plates | Width | Depth | Width | Depth | |
LQGK0606/GA | Full width | 3 | 449 | 449 | 470 | 166 | Product Information |
LQGK0806/GA | 3 | 649 | 449 | 670 | 166 | ||
LQGK1006/GA | Centre Mullion | 6 | 849 | 449 | 420 | 166 | |
LQGK1206/GA | 6 | 1049 | 449 | 520 | 166 | ||
LQGK0608/GA | Full width | 3 | 449 | 649 | 470 | 266 x 2 + 166 x 1 | |
LQGK0808/GA | 3 | 649 | 649 | 670 | 266 x 2 + 166 x 1 | ||
LQGK1008/GA | Centre Mullion | 6 | 849 | 649 | 420 | 266 x 4 + 166 x 2 | |
LQGK1208/GA | 6 | 1049 | 649 | 520 | 266 x 4 + 166 x 2 | ||
LQBK | Baying kit (8 external / 10 internal) /gasket tape/plinth infill | Product Information |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Dimensions (mm) | Fixings (mm) | ||||
Catalogue No. | Height | Width | Height | Width | |
LQMP1404 | 1275 | 275 | 1249 | 249 | Product Information |
LQMP1405 | 1275 | 375 | 1249 | 349 | |
LQMP1406 | 1275 | 475 | 1249 | 449 | |
LQMP1408 | 1275 | 675 | 1249 | 649 | |
LQMP1410 | 1275 | 875 | 1249 | 849 | |
LQMP1412 | 1275 | 1075 | 1249 | 1049 | |
LQMP1604 | 1475 | 275 | 1449 | 249 | |
LQMP1605 | 1475 | 375 | 1449 | 349 | |
LQMP1606 | 1475 | 475 | 1249 | 449 | |
LQMP1608 | 1475 | 675 | 1249 | 649 | |
LQMP1610 | 1475 | 875 | 1249 | 849 | |
LQMP1612 | 1475 | 1075 | 1249 | 1049 | |
LQMP1804 | 1675 | 275 | 1649 | 249 | |
LQMP1805 | 1675 | 375 | 1649 | 349 | |
LQMP1806 | 1675 | 475 | 1649 | 449 | |
LQMP1808 | 1675 | 675 | 1649 | 649 | |
LQMP1810 | 1675 | 875 | 1649 | 849 | |
LQMP1812 | 1675 | 1075 | 1649 | 1049 | |
LQMP2004 | 1875 | 275 | 1849 | 249 | |
LQMP2005 | 1875 | 375 | 1849 | 349 | |
LQMP2006 | 1875 | 475 | 1849 | 449 | |
LQMP2008 | 1875 | 675 | 1849 | 649 | |
LQMP2010 | 1875 | 875 | 1849 | 849 | |
LQMP2012 | 1875 | 1075 | 1849 | 1049 | |
LQMP2204 | 2075 | 275 | 2049 | 249 | |
LQMP2205 | 2075 | 375 | 2049 | 349 | |
LQMP2206 | 2075 | 475 | 2049 | 449 | |
LQMP2208 | 2075 | 675 | 2049 | 649 | |
LQMP2210 | 2075 | 875 | 2049 | 849 | |
LQMP2212 | 2075 | 1075 | 2049 | 1049 | |
Infill Panels | |||||
Catalogue No. | Height | ||||
LQMF1401 | 1275 | ||||
LQMF1601 | 1475 | ||||
LQMF1801 | 1675 | ||||
LQMF2001 | 1875 | ||||
LQMF2201 | 2075 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Dimensions (mm) | To suit frame | ||||
Catalogue No. | Height | Height (mm) | RU | ||
LQSF03RU/SML | 224.5 | Fits all | 3 | Product Information | |
LQSF06RU/SML | 349.5 | Fits all | 6 | ||
LQSF09RU/SML | 499.5 | Fits all | 9 | ||
LQSF12RU/SML | 624.5 | Fits all | 12 | ||
LQSF15RU/SML | 749.5 | Fits all | 15 | ||
LQSF18RU/SML | 899.5 | Fits all | 18 | ||
LQSF22RU | 1094 | Fit All | 22 | ||
LQSF27RU | 1294 | 1400 Full Height | 27 | ||
LQSF33RU | 1494 | 1600 Full Height | 33 | ||
LQSF36RU | 1694 | 1800 Full Height | 36 | ||
LQSF40RU | 1894 | 2000 Full Height | 40 | ||
LQSF45RU | 2094 | 2200 Full Height | 45 | ||
Horizontal Swing Frame Rail | |||||
Catalogue No. | Dimensions (mm) | ||||
Width | Fixing Width | To Fit Frame Width (mm) | |||
LQRF06/SML | 551 | 538 | 600 | ||
LQRF08/SML | 751 | 738 | 800 | ||
LQRF06 | 551 | 538 | 600 | ||
LQRF08 | 751 | 738 | 800 | ||
Position | Catalogue No. | Height | To Fit Swing Frame RU | ||
Side Mount | LQSS3U08 | 152 | LQSF03RU/SML | Product Information | |
LQLS/92268 | Swing handle, Keylockable (92268) | ||||
LQLPAD | Swing Handle, Padlockable |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Dimensions | |||||
Position | Catalogue No. | Height | To Fit Swing Frame RU | ||
Side Mount | LQSS3U08 | 152 | LQSF03RU/SML | Product Information | |
LQSS6U08 | 204 | LQSF06RU/SML | |||
LQSS9U08 | 494 | LQSF09RU/SML | |||
LQSS12U08 | 694 | LQSF12RU/SML | |||
LQSS15U08 | 894 | LQSF15RU/SML | |||
LQSS18U08 | 1018 | LQSF18RU/SML | |||
LQSS22U08 | 1218 | LQSF22RU | |||
LQSS27U08 | 1418 | LQSF27RU | |||
LQSS33U08 | 1518 | LQSF33RU | |||
LQSS36U08 | 1618 | LQSF36RU | |||
LQSS40U08 | 1818 | LQSF40RU | |||
LQSS45U08 | 2018 | LQSF45RU |
Catalogue No | Height | Width | Depth | Product Information | |||
---|---|---|---|---|---|---|---|
Dimensions (mm) | |||||||
Catalogue No. | Height | Width | To Fit Frame Height (mm) | To Suit Enclosure Width (mm) | RU | #Min. No of matrix rails | |
LQRR3U | 144.5 | 35 | Fits All | 600 | 3 | 4 | Product Information |
LQRR6U | 269.5 | 35 | Fits All | 600 | 6 | 4 | |
LQRR9U | 419.5 | 35 | Fits All | 600 | 9 | 4 | |
LQRR12U | 544.5 | 35 | Fits All | 600 | 12 | 4 | |
LQRR15U | 669.5 | 35 | Fits All | 600 | 15 | 4 | |
LQRR18U | 819.5 | 35 | Fits All | 600 | 18 | 6 | |
LQRR21U | 944.5 | 35 | Fits All | 600 | 21 | 6 | |
LQRR24U | 1069.5 | 35 | Fits All | 600 | 24 | 6 | |
LQRR27U | 1219.5 | 35 | Fits All | 600 | 27 | 6 | |
LQRR29U | 1300 | 35 | 1400 & above | 600 | 29 | 6 | |
LQRR34U | 1500 | 35 | 1600 & above | 600 | 34 | 6 | |
LQRR38U | 1700 | 35 | 1800 & above | 600 | 38 | 6 | |
LQRR42U | 1900 | 35 | 2000 & above | 600 | 42 | 6 | |
LQRR47U | 2100 | 35 | 2200 | 600 | 47 | 6 | |
LQRR3U/800 | 149.5 | 134.2 | Fits All | 800 | 3 | 4 | |
LQRR6U/800 | 274.5 | 134.2 | Fits All | 800 | 6 | 4 | |
LQRR9U/800 | 424.5 | 134.2 | Fits All | 800 | 9 | 4 | |
LQRR12U/800 | 549.5 | 134.2 | Fits All | 800 | 12 | 4 | |
LQRR15U/800 | 674.5 | 134.2 | Fits All | 800 | 15 | 4 | |
LQRR18U/800 | 824.5 | 134.2 | Fits All | 800 | 18 | 6 | |
LQRR21U/800 | 949.5 | 134.2 | Fits All | 800 | 21 | 6 | |
LQRR24U/800 | 1074.5 | 134.2 | Fits All | 800 | 24 | 6 | |
LQRR27U/800 | 1224.5 | 134.2 | Fits All | 800 | 27 | 6 | |
LQRR29U/800 | 1312.4 | 134.2 | 1400 & above | 800 | 29 | 6 | |
LQRR34U/800 | 1512.4 | 134.2 | 1600 & above | 800 | 34 | 6 | |
LQRR38U/800 | 1712.4 | 134.2 | 1800 & above | 800 | 38 | 6 | |
LQRR42U/800 | 1912.4 | 134.2 | 2000 & above | 800 | 42 | 6 | |
LQRR47U/800 | 2112.4 | 134.2 | 2200 | 800 | 47 | 6 |
Catalogue No | Height | Width | Product Information |
---|---|---|---|
Catalogue No. | Nominal Width | To suit frame dimension | |
LQRM01 | 119 | – | Product Information |
LQRM02 | 219 | – | |
LQRM03 | 319 | 400 | |
LQRM04 | 419 | 500 | |
LQRM05 | 519 | 600 | |
LQRM06 | 619 | – | |
LQRM07 | 719 | 800 | |
LQRM08 | 819 | – | |
LQRM09 | 919 | 1000 | |
LQRM10 | 1019 | – | |
LQRM11 | 1119 | 1200 | |
LQRM12 | 1219 | – | |
LQRM13 | 1319 | 1400 | |
LQRM14 | 1419 | – | |
LQRM15 | 1519 | 1600 | |
LQRM16 | 1619 | – | |
LQRM17 | 1719 | 1800 | |
LQRM18 | 1819 | – | |
LQRM19 | 1919 | 2000 | |
LQRM20 | 2019 | – | |
LQRM21 | 2119 | 2200 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Catalogue No | External Single Door | ||||
Catalogue No | External Door | ||||
Horizontal Swing Frame Rail | |||||
Catalogue No. | Height | Width | To Fit Frame Height (mm) | To Suit Enclosure Width (mm) | |
LQRR3U | 144.5 | 35 | Fits All | 600 | Product Information |
LQRM01 | 119 | – | Product Information | ||
Dimensions (mm) | |||||
Type | Catalogue No. | Width | Fixings | To suit frame (mm) | |
25mm Profile Rail | LQRP04/25 | 358 | 338 | 400 | Product Information |
LQRP05/25 | 458 | 438 | 500 | ||
LQRP06/25 | 558 | 538 | 600 | ||
LQRP08/25 | 758 | 738 | 800 | ||
50mm Profile Rail | LQRP04/50 | 358 | 338 | 400 | |
LQRP05/50 | 458 | 438 | 500 | ||
LQRP06/50 | 558 | 538 | 600 | ||
LQRP08/50 | 758 | 738 | 800 | ||
Door Rail | LQRD04 | 288 | 268 | 400 | |
LQRD05 | 388 | 368 | 500 | ||
LQRD06 | 488 | 468 | 600 | ||
LQRD08 | 688 | 668 | 800 | ||
Vertical Rail | |||||
LQRV13 | 1358 | 1400 | Product Information | ||
Horizontal Rail | |||||
Door Rail | |||||
LQRD04 | 288 | 268 | 400 | Product Information | |
Please Note: Plan holder mounts to existing door rail | |||||
* Horizontal door rail required - see table below | |||||
LQLL | Laptop Lectern for iLINQ range | 600 | Door Rail* | ||
Door Rail |
Catalogue No | Height | Width | Depth | Product Information | ||
---|---|---|---|---|---|---|
External Dimensions (mm) | To suit enclosure (mm) | |||||
Catalogue No. | Height | Width | Locking Height | Height | Width | |
LQHE1305 | 1296 | 400 | 1242 | 1400 | 500 | Product Information |
LQHE1306 | 1296 | 500 | 1242 | 1400 | 600 | |
LQHE1308 | 1296 | 700 | 1242 | 1400 | 800 | |
LQHE1505 | 1496 | 400 | 1442 | 1600 | 500 | |
LQHE1506 | 1496 | 500 | 1442 | 1600 | 600 | |
LQHE1508 | 1496 | 700 | 1442 | 1600 | 800 | |
LQHE1705 | 1696 | 400 | 1642 | 1800 | 500 | |
LQHE1706 | 1696 | 500 | 1642 | 1800 | 600 | |
LQHE1708 | 1696 | 700 | 1642 | 1800 | 800 | |
LQHE1905 | 1896 | 400 | 1842 | 2000 | 500 | |
LQHE1906 | 1896 | 500 | 1842 | 2000 | 600 | |
LQHE1908 | 1896 | 700 | 1842 | 2000 | 800 | |
LQHE2105 | 2096 | 400 | 2042 | 2200 | 500 | |
LQHE2106 | 2096 | 500 | 2042 | 2200 | 600 | |
LQHE2108 | 2096 | 700 | 2042 | 2200 | 800 | |
Vertical Rail | ||||||
Catalogue No. | Height | To suit enclosure height (mm) | ||||
LQRV13 | 1358 | 1400 | Product Information | |||
LQRV15 | 1558 | 1600 | ||||
LQRV17 | 1758 | 1800 | ||||
LQRV19 | 1958 | 2000 | ||||
LQRV21 | 2158 | 2200 | ||||
Horizontal Rail | ||||||
Catalogue No. | Width | To suit enclosure width (mm) | ||||
LQRH05 | 405 | 500 | ||||
LQRH06 | 505 | 600 | ||||
LQRH08 | 705 | 800 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
External Dimensions (mm) | Fixing Dimensions (mm) | ||||
Catalogue No. | Height | Depth | Height | Depth | |
LQVS1404 | 1297 | 297 | 1319 | 319 | Product Information |
LQVS1405 | 1297 | 397 | 1319 | 419 | |
LQVS1406 | 1297 | 497 | 1319 | 519 | |
LQVS1408 | 1297 | 697 | 1319 | 719 | |
LQVS1604 | 1497 | 297 | 1519 | 319 | |
LQVS1605 | 1497 | 397 | 1519 | 419 | |
LQVS1606 | 1497 | 497 | 1519 | 519 | |
LQVS1608 | 1497 | 697 | 1519 | 719 | |
LQVS1804 | 1697 | 297 | 1719 | 319 | |
LQVS1805 | 1697 | 397 | 1719 | 419 | |
LQVS1806 | 1697 | 497 | 1719 | 519 | |
LQVS1808 | 1697 | 697 | 1719 | 719 | |
LQVS2004 | 1897 | 297 | 1919 | 319 | |
LQVS2005 | 1897 | 397 | 1919 | 419 | |
LQVS2006 | 1897 | 497 | 1919 | 519 | |
LQVS2008 | 1897 | 697 | 1919 | 719 | |
LQVS2204 | 2097 | 297 | 2119 | 319 | |
LQVS2205 | 2097 | 397 | 2119 | 419 | |
LQVS2206 | 2097 | 497 | 2119 | 519 | |
LQVS2208 | 2097 | 697 | 2119 | 719 |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Dimensions (mm) | |||||
Suits Door Size | Catalogue No | Width | Depth | Suits | |
400mm | LQPH04/35 | 280 | 38 | A4 | Product Information |
LQPH04/80 | 280 | 81 | A4 | ||
500mm | LQPH05/35 | 380 | 38 | A3 Portrait | |
LQPH05/80 | 380 | 81 | A3 Portrait | ||
600mm & 800 | LQPH06/35* | 39 | - | A3 | |
LQPH06/80* | 85 | - | A3 | ||
Door Rail | |||||
LQRD04 | 288 | 268 | 400 | Product Information | |
LQRD05 | 388 | 368 | 500 | ||
LQRD06 | 488 | 468 | 600 | ||
LQRD08 | 688 | 668 | 800 | ||
Please Note: Plan holder mounts to existing door rail | |||||
* Horizontal door rail required - see table below |
Catalogue No | Height | Width | Depth | Product Information | |
---|---|---|---|---|---|
Catalogue No. | Description | Door Width (mm) | Also Required | ||
LQLL | Laptop Lectern for iLINQ range | 600 | Door Rail* | ||
800 | Product Information | ||||
Door Rail | |||||
LQRD04 | 288 | 268 | 400 | ||
LQRD05 | 388 | 368 | 500 | ||
LQRD06 | 488 | 468 | 600 | ||
LQRD08 | 688 | 668 | 800 |
Catalogue No | Height | Width | Depth | Product Information | ||||||
---|---|---|---|---|---|---|---|---|---|---|
Inclusions | Required Mounting Bracket | To suit enclosure | ||||||||
Catalogue No. | LED Light | Power Supply | Splitter | Switch | Connectors | LQLKB03 | LQLKB05 | Width (mm) | Optional | |
BRLED300 | • | • | • | • | 400 | BRMOT PIR Motion Sensor | Product Information | |||
BRLED500 | • | • | • | • | 600 & 800 | |||||
BRLEDK03 | • | • | • | • | 400 | |||||
BRLEDK05 | • | • | • | • | 600 & 800mm |
[/vc_accordion_tab
Downloads
Product Leaflet (8.3MB)
iLINQ Catalogue (20.1MB)
Specification Guide (1.4MB)
Product Spotlight Flyer (500kB)
iLINQ Technical Guide (4.9MB)
Accessories
Catalogue No | Height | Product Information |
---|---|---|
The baying kit available for iLINQ is designed to be fitted in a multitude of places, maximising space and flexibility. | ||
Catalogue No | Description | |
LQBK | Baying kit (8 external / 10 internal) /gasket tape/plinth infill | Product Information |
LQMF1401 | Mounting pan infill 1400 high | |
LQMF1601 | Mounting pan infill 1600 high | |
LQMF1801 | Mounting pan infill 1800 high |
Catalogue No | Height | Product Information |
---|---|---|
Catalogue No | Description | |
LQLA7S | Lock assembly 7mm square, 8mm triangle, 3mm double bit | Product Information |
LQLS/92268 | Swing handle, Keylockable (92268) | |
LQLPAD | Swing Handle, Padlockable | |
SKZ | Key - metal 4 way (7mm square, 8mm triangle, 3mm double-bit, 8mm triangle) |
Catalogue No | Height | Width | Product Information |
---|---|---|---|
Catalogue No | Description | Quantity | |
LQATK | Allen Key Tools | Product Information | |
LQDS | Door Stay (white) | ||
LQCG06 | Cage nuts M6 (front access) | 20 | |
LQCG08 | Cage nuts M8 (front access) | 20 | |
ARCN | Cage nuts M6 (rear access) includes washers and screws | 50 | |
LQB0512 | Button head hex drive set screws (M5 x 12) | 20 | |
LQB0612 | Button head hex drive set screws (M6 x 12) | 20 | |
LQB0812 | Button head hex drive set screws (M8 x 12) | 20 | |
LQB0616 | Button head hex drive set screws (M6 x 16) | 20 | |
LQB0620 | Button head hex drive set screws (M6 x 20) | 20 | |
LQB0825 | Button head hex drive set screws (M8 x 25) | 20 | |
IPWS06 | Star washers M6 | 20 | |
IPWS08 | Star washers M8 | 20 | |
IPWF06 | Flat washers M6 | 20 | |
IPWF08 | Flat washers M8 | 20 | |
LQGN | Clamp nut for fixing gland plates to frame | 20 |
Projects
Oyu Tolgoi Mine
The Oyu Tolgoi mine required custom switchboards, PLC panels, local control stations and enclosures for use on the mine site.
Ichthys Gas Field
Atlantic, Gulf and Pacific (AG&P) was contracted to undertake the design and construction of on and off-shore modules for the Ichthys Gas Field located off the coast of Western Australia.
Total Marine Technology
Total Marine Technology (TMT) is an Australian based company who specialise in the design, engineering, building and operation of ROVs (Remotely Operated Vehicles) and subsea tooling.
~
