Anti-condensation Heater

The WID range of anti-condensation heaters suitable for installation in all enclosures and protect equipment from water damage due to condensation.

Anti-condensation Heater

Product Information

Applications

Used in enclosures where low temperature or high humidity may cause condensation to form in the enclosure, damaging equipment.

Features

  • IP20 protection rating – more info on IP ratings
  • Heating capacities from 10 to 550W
  • Easy ‘click in’ installation on 35mm DIN rails
  • Range of power supplies
  • Optional temperature control thermostat or humidistat
  • Minimal maintenance

Construction

  • Die cast aluminium
  • Plastic parts rated to UL 94 V-0

DownloadsAccessoriesMore ProductsEnquiryOnline StockistsLocal Stockists

Order Guide

Part NumberDescriptionSupply (V)Heating Capacity (W)*HeightWidthDepth
TX-WID05ZX0XStandard heater, aluminium casing 110-250 AC/DC 451097050
TX-WID10ZX0XStandard heater, aluminium casing 110-250 AC/DC 1001847050
TX-WID15ZX0XStandard heater, aluminium casing 110-250 AC/DC 1502647050
Part NumberDescriptionSupply (V)Heating Capacity (W)*HeightWidthDepth
TX-WID01ZX0PStandard heater with plastic cover 110-250 AC/DC 10993879
TX-WID02ZX0PStandard heater with plastic cover 110-250 AC/DC 20993879
TX-WID03ZX0PStandard heater with plastic cover 110-250 AC/DC 30993879
TX-WID05ZX0PStandard heater with plastic cover 110-250 AC/DC 501106090
TX-WID10ZX0PStandard heater with plastic cover 110-250 AC/DC 1001506090
TX-WID15ZX0PStandard heater with plastic cover 110-250 AC/DC 1501506090
Part NumberDescriptionSupply (V)Heating Capacity (W)*HeightWidthDepth
TX-WID10BL0CFan Forced compact heater, plastic casing230 AC 1ph 1001128047
TX-WID15BL0CFan Forced compact heater, plastic casing230 AC 1ph 1501128047
TX-WID20BL0CFan Forced compact heater, plastic casing230 AC 1ph 20015111947
TX-WID30BL0CFan Forced compact heater, plastic casing230 AC 1ph 30015111947
TX-WID40BL0CFan Forced compact heater, plastic casing230 AC 1ph 40015111947
Part NumberDescriptionSupply (V)Heating Capacity (W)*HeightWidthDepth
TX-WID35BL0TFan forced with thermostat and plastic casing230 AC 1ph 350165100128

* Heating capacity at ambient of 20ºC
