Telecom BD

Building & Campus Distribution enclosures suitable for voice or data cabling up to 500 pairs at or beyond the network boundary.

Telecom BD

Product Information

Applications

Suitable for inside or outside applications for voice or data cabling.

Features

IP30 protection rating for internal enclosures
IP54 protection rating for external enclosures
Coin operated camlocks supplied as standard
Adjustable depth surrounds supplied with enclosures for flush or surface mounting
Backmount frames fitted to all enclosures (plus earthing strips in 20 pair enclosures and jumper guides in 100, 250 and 500 pair enclosures)

Construction

Manufactured from 1mm zinc coated steel
Powdercoated light grey RAL7035

Enquiry Form

Name
First Last
Company
Postcode*
Country
Email*
Phone
Your Enquiry*
I am interested in one of the products on the Telecom BD page of your website.
Your Enquiry*
What would you like to ask us about today?
Newsletter
- Subscribe to our Newsletter
Solve To Submit

Downloads Accessories More Products Enquiry Online Stockists Local Stockists

Order Guide

Part Number	Application	Modules*	Height (mm)	Width (mm)	Depth (mm)	Enquiry
A20	Internal	2	200	200	55	Enquiry
A100	Internal	11	390	290	90	Enquiry
A250	Internal	27	800	290	100	Enquiry
A500	Internal	54	800	490	100	Enquiry
B20	External	2	205	305	80	Enquiry
B100	External	11	405	305	90	Enquiry
B250	External	27	800	305	100	Enquiry
B500	External	54	800	305	100	Enquiry

Downloads

Product Leaflet Technical (230kB)

Features and Benefits (90kB)

Data ICT Catalogue (9.2MB)

Accessories

Accessories

Keys

Product	Description	Part Number
Key Locks	Keyed to 92268 complete with fixings	TKL/92268
Key Locks	Keyed to L331 complete with fixings	TKL/L331

~
