South Australia Rebated Sides

An IP23 South Australia residential rebated sides metering enclosures for SA applications. Designed for both single and multi-phase installations.
South Australia Rebated Sides
Australian Made
Australian Made

Product Information

Applications

Suitable for domestic and light commercial metering installations.

Features

  • Standard SA rebate to allow enclosure to be recessed into the wall easily.
  • Provision to fit ES coin lock (CL) to door of the enclosure.
  • Includes neutral links and earth.

Construction

  • Manufactured from 1.0mm galvanised steel to Z275
  • Powdercoated light grey RAL7035

DownloadsAccessoriesMore ProductsEnquiryOnline StockistsLocal Stockists

Order Guide

Part NumberTo suit meteringDINHeight (mm)Width (mm)Depth (mm)
1DIN25RMIBType 125-pole600470265

Accessories

Part NumberDescription
1DK18-pole DIN kit - Upgrades of old 1MB switchboard from fuses to DIN
CLCoin Lock - Supplied with 2 keys, SAPN master key "series 97000"
2RMI/3PKIT+3 diameter upgrade kit with 2 additional MCB lock-off devices

+ Available on request
