Order Guide
| Part No. | DIN | Dimensions | Panel | Available | ||||
|---|---|---|---|---|---|---|---|---|
| Q20/1PCW | 24-pole | 690 | 485 | 278 | 480 | 461 | 75 | |
| Q20/3PCW | 24-pole | 690 | 485 | 278 | 480 | 461 | 75 | |
Includes meter neutral link fitted to rear of panel
Horizon Q20 Pre-Wired
Product Information
Applications
Providing safety, quality and performance, the Horizon Q20 Pre-wired enclosures are suitable for domestic and light commercial metering installations. Complying with the QLD Supply Authority Rules and Regulations, the Horizon Q20 Pre-wired is designed for both single and 3-phase installations.
Features
- Designed for both single and three-phase installations.
- 3.75m main earth tail
- Meter neutral pre-wired
- Comes standard pre-wired with a 63A Schneider main switch
- AS/NZS 3012 compliant for construction sites as standard.
- Suitable for domestic and light commercial metering applications.
- Self closing gravity catch.
- Top cable entry has ratchet aperture shut-off slide.
- RotaDIN® rotating / removable DIN section.
- Cord retainer for easy retention of extension cords.
- Circuit identification label area with protective cover.
- Weatherproof installation label for AS/NZS3000 compliance.
- External frame mounting brackets.
Construction
- Manufactured from 1.0 galvanised steel
- Powdercoated Light Grey RAL7035
~
