Showing 1–18 of 210 results
Horizon Meter Box for Queensland, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 860H x 485W x 278D to fit standard stud framing, with 48 poles of DIN rail space. Includes an E16P earth link, N32P neutral link, earthing stud and ID labels.
Horizon Meter Box for Queensland, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 690H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space. Includes a meter isolator link, E9P earth link, N18P neutral link, earthing stud and ID labels.
Horizon Meter Box for Queensland, IP23 rated for single and three-phase applications. Manufactured from 316 stainless steel with N4 surface finish. Dimensions are 690H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space. Includes a meter isolator link, E9P earth link, N18P neutral link, earthing stud and ID labels.
Infinity 3G – 2170Hx670Wx450D made from zinc coated steel and rated to IP66. A pre-wired enclosure suitable QLD commercial / telecom applications and designed for a 6 x 3-phase metering applications. This unit includes a main incoming 250A MCCB, meter protection fuses and internal wiring between the MCCB and protection fuses only.
Horizon Meter Box for New South Wales, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 690H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space. Includes an E9P earth link, N18P neutral link and earthing stud
Horizon Meter Box for New South Wales, IP23 rated for single and three-phase applications. Manufactured from 316 stainless steel with N4 surface finish. Dimensions are 690H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space. Includes an E9P earth link, N18P neutral link and earthing stud.
Infinity 3G – 2170Hx670Wx450D made from zinc coated steel and rated to IP66. A pre-wired enclosure suitable NSW applications and designed for a 6 x 3-phase metering applications. This unit includes a main incoming 250A MCCB, meter protection fuses and internal wiring between the MCCB and protection fuses only.
Horizon Meter Box for New South Wales, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 860H x 485W x 278D to fit standard stud framing, with 48 poles of DIN rail space. Includes an E9P earth link, N19P neutral link and earthing stud.
Horizon Meter Box for Victoria, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 690H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space. Includes a neutral link (N18P + stud) and service fuse.
Horizon Meter Box for Victoria, IP23 rated for single and three-phase applications. Manufactured from 316 stainless steel with an N4 surface finish. Dimensions are 690H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space. Includes a neutral link (N18P + stud) and service fuse.
Horizon Meter Box for Victoria, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 430H x 485W x 278D to fit standard stud framing. Includes a panel only.
Horizon Meter Box for Victoria, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 430H x 485W x 278D to fit standard stud framing. Includes a panel and service fuse.
Horizon Meter Box for Victoria, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 860H x 485W x 278D to fit standard stud framing, with 48 poles of DIN rail space. Includes a neutral link (2 x N18P + stud) and service fuse.
Horizon Meter Box for Victoria, IP23 rated for single-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 430H x 485W x 278D to fit standard stud framing, with 20 poles of DIN rail space. Includes a neutral link and service fuse.
Horizon Meter Box for Tasmania, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 688H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space.
Horizon Meter Box for Tasmania, IP23 rated for single and three-phase applications. Manufactured from 316 stainless steel with N4 surface finish. Dimensions are 688H x 485W x 278D to fit standard stud framing, with 24 poles of DIN rail space.
Horizon Meter Box for Tasmania, IP23 rated for single and three-phase applications. Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 860H x 485W x 278D mm to fit standard stud framing, with 36 poles of DIN rail space.
Horizon Meter Box for Tasmania, IP23 rated and compliant with supply authority requirements for properties with two separate multi-phase meters (two NMIs). Manufactured from galvanised steel powdercoated Light Grey RAL7035. Dimensions are 860H x 485W x 278D mm to fit standard stud framing, with 9 + 12 poles of DIN rail space.
